Name | Medium VAN |
Brand | Fengjing |
Model | VK1 |
Model | VIEW CS2 |
Usage | Passenger Transport |
Wheelbase (Whole Vehicle) | 5390 mm |
BUF | 4F20 |
Vehicle No. | 6549B1DAA-RZZA06 |
Announcement Model | BJ6549B1DAA-RZ |
Rear Door Configuration Details | With defroster + rear wiper + ground view mirror |
Drive Type | 4×2 |
Wheelbase (mm) | 3110 |
Overall Dimension (mm) | 5390×1920×2285 |
Curb Weight (kg) | 2270 |
GVW (kg) | 3400 |
Body Width (mm) | 1920 |
Roof Height | High roof |
Left / Right Hand Drive | RHD |
Cab Configuration | Full trim |
Number of Seats (Passenger capacity) | 15 |
Fuel Type | Diesel |
Engine Model | 4F20TC10 |
Engine Manufacture | Beiqi Foton Motor Co., Ltd. |
Displacement(ml) / Battery Capacity (kwh) | 1968 |
Emission Standard | Euro IV |
Power/Speed (kw/rpm) | 101 |
Engine Torque (Nm/rpm) | 330 |
Transmission Model | ZM036 |
Transmission Type | 6MT |
Transmission Manufacturer | Zhongma |
Middle / Rear Axle Load Capacity | 1800 |
Drive Axle Ratio | 4.556 |
Brake Type | Rear wheel-mounted hand brake |
Brake Form | Front disc, rear drum |
Brake Control System | ABS+EBD+ESC |
Tire Model | 195R15C aluminum wheels + steel spare wheel |
Number of Tires | 5 |
Fuel Tank Capacity | 65L |
Suspension Type | Front: Double wishbone independent suspension with torsion bar spring Rear: Leaf spring non-independent suspension |
Leaf Spring Count | Rear: 3+2 |
