XC360
XCMG
8428909090
| Main technical performance | ||
| Item | Parameter | |
| Complete machine weight(kg) | 19700 | |
| Engine model | WEICHAI WD10G240E201 | |
| Engine power | 178KW/2200rpm | |
| Displacement | 10L | |
| Gear | Forward 4/Reverse 4 | |
| Speed(Km/h) | Forward 1/Reverse 1 | 6/6 |
| Forward 2/Reverse 2 | 11/11 | |
| Forward 3/Reverse 3 | 22/22 | |
| Forward 4/Reverse 4 | 34/34 | |
| Steering angle(°) | 38 | |
| Tire model | 23.5-25 | |
| Pattern | Chevron | |
| Swing angle for front axle(°) | ±12 | |
| Winch drive type | Hydraulic motor drive | |
| Max wire rope traction | 204KN | |
| Max wire rope speed | 10m/min | |
| Drum capacity (Diameter mm×Length mm) | Φ22mmX33m | |
| Winch drum diameter mm(Cable type) | 273 | |
| Winch drum width mm | 230 | |
| Push plate lifting height mm | 1381 | |
| Push plate cutting depth mm | 456 | |
| Tuming radius(outside oftires)mm | 6370 | |
| Complete machine width(outside of tires)mm | 3220 | |
| Complete machine height(Cab)mm | 3550 | |
| Tire radius mm | 760 | |
| Ground to guide frame top height mm | 2700 | |
| Wheel base mm | 3680 | |
| Wheel track mm | 2622 | |
| Main technical performance | ||
| Item | Parameter | |
| Complete machine weight(kg) | 19700 | |
| Engine model | WEICHAI WD10G240E201 | |
| Engine power | 178KW/2200rpm | |
| Displacement | 10L | |
| Gear | Forward 4/Reverse 4 | |
| Speed(Km/h) | Forward 1/Reverse 1 | 6/6 |
| Forward 2/Reverse 2 | 11/11 | |
| Forward 3/Reverse 3 | 22/22 | |
| Forward 4/Reverse 4 | 34/34 | |
| Steering angle(°) | 38 | |
| Tire model | 23.5-25 | |
| Pattern | Chevron | |
| Swing angle for front axle(°) | ±12 | |
| Winch drive type | Hydraulic motor drive | |
| Max wire rope traction | 204KN | |
| Max wire rope speed | 10m/min | |
| Drum capacity (Diameter mm×Length mm) | Φ22mmX33m | |
| Winch drum diameter mm(Cable type) | 273 | |
| Winch drum width mm | 230 | |
| Push plate lifting height mm | 1381 | |
| Push plate cutting depth mm | 456 | |
| Tuming radius(outside oftires)mm | 6370 | |
| Complete machine width(outside of tires)mm | 3220 | |
| Complete machine height(Cab)mm | 3550 | |
| Tire radius mm | 760 | |
| Ground to guide frame top height mm | 2700 | |
| Wheel base mm | 3680 | |
| Wheel track mm | 2622 | |
