Tare weight | 10000kg |
Size | 12995*2500*4000mm |
Volume | 45M3 |
Tank body | Aluminum alloy 5454 6mm |
End plate | Aluminum alloy 5454 |
Axle | 3 axle FUWA brand 13T |
Suspension | Mechanical suspension American type local brand |
Leaf spring | Leaf spring 10pcs*90*13mm |
Manhole cover | 500mm manhole cover .2 sets |
Tire | 12R22.5 double star brand 12pcs |
Wheel rim | 9.0-22.5 better brand 12pcs |
Discharge valve | 4disc valve |
Discharge pipe | 4seamless steel tube |
Outlet pipe | 4rubber hose.6m |
Kingpin | JOST brand 2 bolt-in king pin |
Landing gear | JOST brand two-speed, manual operating ,heavy duty landing gear 24T |
Engine | Diesel engine: weichai brand model: 4102. |
Air compressor | 37 KW, 0.2Mpa. 1000r/Min |
Braking system | WABCO RE6 relay valve ;T30/30 spring brake chamber;40L air tanks |
ABS | Optional |
Light | LED 8 side lights and 2 rear lights 2 width lamp |
Air-charging system | 2main hole.2check valve .1.5safe valve.0.4Mpa.gauge |
Quadratic blow | 1 diameter check valve |
Painting | Complete chassis sand blasting to clean rust ,1coat of anticorrosive prime,2coats of final paint |
Accessories | One standard tool box,one spare tire carrier,one crank,one shaft head wrench,four side light,two rear light |
Core Features
Material & Capacity Advantages
40m³ Large-Capacity Aluminum Tank: Optimizes fuel payload, enabling more efficient long-distance transport and reducing delivery trips.
High-Strength Aluminum Alloy 5454 Construction: Offers superior corrosion resistance, longer service life, and lighter weight for improved fuel efficiency.
Structural & Performance Reliability
3-Axle FUWA Axle Configuration: Ensures balanced load distribution, excellent road stability, and compliance with global transport regulations.
Durable Suspension System: Leaf spring suspension (10pcs×90×13mm) absorbs road shocks, protecting the tank and improving ride comfort.
Safety & Compliance
Advanced Safety Systems: Equipped with emergency shut-off valves, anti-static grounding, pressure relief devices, and anti-wave baffles to prevent accidents.
Precision Welding & Leak Testing: Automatic welding technology and strict pressure tests guarantee leak-proof performance for safe fuel transport.
ISO9001 & CCC Certifications: Meets international quality and safety standards, ensuring reliability in global markets.
Operational Efficiency
Efficient Loading/Unloading System: Top loading and bottom unloading design ensures quick, convenient operation, saving time and labor.
Customizable Compartments: 1-7 optional compartments allow separate transport of different petroleum products, enhancing versatility.
Design & Practicality
LED Lighting System: 8 side lights, 2 rear lights, and 2 width lamps ensure visibility and safety during night operations.
Factory-Direct Pricing & Quality Control: Strict quality inspection and direct supply eliminate middlemen, offering competitive prices and reliable performance.
Typical Uses
Long-Distance Fuel Transport
Diesel & Gasoline Long-Distance Transport: Ideal for cross-border and intercity fuel distribution, maximizing payload and reducing costs.
International Fuel Transport Operations: Complies with international transport standards, suitable for export to global markets.
Logistics & Supply Chain
Oil Depot to Fuel Station Delivery: Efficiently transports fuel from storage depots to retail stations, ensuring timely supply.
Petroleum & Energy Logistics: Supports industrial fuel needs, delivering diesel to factories, construction sites, and power plants.
FAQ
Material & Design
What is the advantage of aluminum alloy 5454 over steel for the fuel tank?
Aluminum alloy 5454 is corrosion-resistant, lightweight (reducing tare weight by 30%), and offers better fuel efficiency. It also has a longer service life and requires less maintenance compared to steel tanks.
Configuration & Versatility
How many compartments can the 40m³ fuel tank semi trailer have?
The trailer offers 1-7 optional compartments, allowing simultaneous transport of multiple petroleum products (e.g., diesel and gasoline), enhancing operational flexibility.
Safety & Compliance
What safety features prevent fuel leaks during transport?
It includes precision-welded seams, strict leak testing, anti-wave baffles, emergency shut-off valves, and anti-static grounding, ensuring 100% leak-proof and safe fuel transport.
Does the trailer comply with international transport standards?
Yes, it holds ISO9001 and CCC certifications and meets global transport regulations, making it suitable for international fuel transport operations.
Customization & Support
Can the trailer be customized with different axle brands or suspension types?
Absolutely. We offer customizable options for axle brands (FUWA or others), suspension types (leaf spring or air suspension), and accessories to meet specific regional requirements.
