JSIE90YQ
JSIE
8704109000
Maker: | SINOTRUK |
Model: | JSIE5507S3840AJ |
Driving type: | 6x4 |
Made year: | brand new |
Cab: | HW7D standard cabin, with air conditioner |
Engine: | WD615.47, 371HP, 273Kw at 2200 rpm, Euro II emission standard, with displacement of 9.726L, 4 stroke, direct injection diesel engine, 6 cylinder in-line with water cooling, turbo-charging intercooling, Maximum torque of 1500Nm at 1100~1600 rpm |
Transmission: | HW21712 (12 forwards and 2 reverses, manual) |
Front axle: | HF10 (10000Kg)(drum brake) |
Rear axle: | AC16 (2X16000Kg) (i=6.73) (drum brake) |
Suspension: | reinforced leaf springs, 10/13 pcs |
Tires: | 13.00-25, tube, 11 pcs |
Fuel tank: | 400L, aluminum with lock cap |
Steering: | ZF8098 power steering , hydraulic steering with power assistance, ratio: 22.2-26.2 |
Dumping Body: | 5800*2800*1600mm, 26cbm, manganese material, thickness of bottom plate 12mm, thickness of side walls 10mm, with rear gates, HYVA 179 front lifting mechanism |
Overall Measurements: | 8700*3100*4130mm |
Gross Vehicle Weight: | 50000kg |
Color: | Grey (optional) |
The 90 Tons Heavy Duty Mineral Dump Truck offers an impressive 90-ton gross weight capacity, making it ideal for bulk mineral and ore transportation. Its large load capacity reduces the number of trips required, significantly improving hauling efficiency and lowering operational costs for mining and quarry operations.
Equipped with a Weichai 420HP engine (Euro 3 emission standard) and FAST BEAND 7DS220 transmission, the mining dump truck delivers superior power and torque. The optimized powertrain ensures excellent climbing ability on steep slopes and stable performance during long-distance transport, even under full load. The advanced cooling system prevents overheating during 24/7 continuous operation.
Built to withstand extreme mining conditions, the truck features a reinforced heavy-duty steel frame and wear-resistant dump body. The high-enforced steel/manganese dump body resists abrasion from sharp minerals and ores, while the reinforced leaf spring suspension (10/13 pcs) enhances load-bearing capacity and shock absorption on rough terrains.
The ergonomic cabin is designed for operator comfort and safety. Equipped with air conditioning, wide-visibility windows, and a front roll-type structure, it provides a comfortable working environment even during long shifts. The ZF8098 power steering system reduces driving fatigue, while the reliable drum brake system ensures safety on slopes and uneven surfaces.
The Ore Transport Truck is engineered for durability and easy maintenance. With accessible maintenance points and long-life components, it minimizes downtime and reduces maintenance costs. The robust design and high-quality materials ensure a long service life, making it a cost-effective investment for mining companies.
Ideal for open-pit mines, the 90 Tons Heavy Duty Mineral Dump Truck efficiently hauls coal, iron ore, copper, and other minerals from mining sites to processing facilities. Its high payload capacity and rugged construction make it suitable for harsh mining environments with rough roads and steep slopes.
Quarries and aggregate production sites rely on this quarry dump truck to transport limestone, gravel, and other aggregates. The wear-resistant dump body and powerful engine ensure efficient hauling of abrasive materials, supporting high-volume production requirements.
For large construction projects such as highways, dams, and industrial parks, the truck excels in earthmoving and overburden removal. Its 90-ton capacity and front lifting mechanism enable fast and efficient loading and unloading of soil, rock, and debris.
Specialized in transporting heavy minerals, the large-capacity mining tipper is widely used in the energy and construction industries. It provides a reliable and efficient solution for long-distance transport of coal to power plants, iron ore to steel mills, and limestone to cement factories.
The gross weight is 92 tons, with a load capacity of 60 tons, making it suitable for heavy mineral and material transport.
Yes, the dump body is made of high-enforced steel or manganese material, which is wear-resistant and can withstand the abrasion of sharp minerals, ores, and aggregates.
The truck comes with left-hand driving (LHD) as standard, with customizable options available upon request to meet regional requirements.
The tires hold ECE, GCC, ISO, and DOT certifications, ensuring high quality, durability, and compliance with international safety standards.
We ship from Qingdao and Shanghai ports, with flexible arrangements possible based on your location and logistics needs. Payment terms include T/T and L/C.
Maker: | SINOTRUK |
Model: | JSIE5507S3840AJ |
Driving type: | 6x4 |
Made year: | brand new |
Cab: | HW7D standard cabin, with air conditioner |
Engine: | WD615.47, 371HP, 273Kw at 2200 rpm, Euro II emission standard, with displacement of 9.726L, 4 stroke, direct injection diesel engine, 6 cylinder in-line with water cooling, turbo-charging intercooling, Maximum torque of 1500Nm at 1100~1600 rpm |
Transmission: | HW21712 (12 forwards and 2 reverses, manual) |
Front axle: | HF10 (10000Kg)(drum brake) |
Rear axle: | AC16 (2X16000Kg) (i=6.73) (drum brake) |
Suspension: | reinforced leaf springs, 10/13 pcs |
Tires: | 13.00-25, tube, 11 pcs |
Fuel tank: | 400L, aluminum with lock cap |
Steering: | ZF8098 power steering , hydraulic steering with power assistance, ratio: 22.2-26.2 |
Dumping Body: | 5800*2800*1600mm, 26cbm, manganese material, thickness of bottom plate 12mm, thickness of side walls 10mm, with rear gates, HYVA 179 front lifting mechanism |
Overall Measurements: | 8700*3100*4130mm |
Gross Vehicle Weight: | 50000kg |
Color: | Grey (optional) |
The 90 Tons Heavy Duty Mineral Dump Truck offers an impressive 90-ton gross weight capacity, making it ideal for bulk mineral and ore transportation. Its large load capacity reduces the number of trips required, significantly improving hauling efficiency and lowering operational costs for mining and quarry operations.
Equipped with a Weichai 420HP engine (Euro 3 emission standard) and FAST BEAND 7DS220 transmission, the mining dump truck delivers superior power and torque. The optimized powertrain ensures excellent climbing ability on steep slopes and stable performance during long-distance transport, even under full load. The advanced cooling system prevents overheating during 24/7 continuous operation.
Built to withstand extreme mining conditions, the truck features a reinforced heavy-duty steel frame and wear-resistant dump body. The high-enforced steel/manganese dump body resists abrasion from sharp minerals and ores, while the reinforced leaf spring suspension (10/13 pcs) enhances load-bearing capacity and shock absorption on rough terrains.
The ergonomic cabin is designed for operator comfort and safety. Equipped with air conditioning, wide-visibility windows, and a front roll-type structure, it provides a comfortable working environment even during long shifts. The ZF8098 power steering system reduces driving fatigue, while the reliable drum brake system ensures safety on slopes and uneven surfaces.
The Ore Transport Truck is engineered for durability and easy maintenance. With accessible maintenance points and long-life components, it minimizes downtime and reduces maintenance costs. The robust design and high-quality materials ensure a long service life, making it a cost-effective investment for mining companies.
Ideal for open-pit mines, the 90 Tons Heavy Duty Mineral Dump Truck efficiently hauls coal, iron ore, copper, and other minerals from mining sites to processing facilities. Its high payload capacity and rugged construction make it suitable for harsh mining environments with rough roads and steep slopes.
Quarries and aggregate production sites rely on this quarry dump truck to transport limestone, gravel, and other aggregates. The wear-resistant dump body and powerful engine ensure efficient hauling of abrasive materials, supporting high-volume production requirements.
For large construction projects such as highways, dams, and industrial parks, the truck excels in earthmoving and overburden removal. Its 90-ton capacity and front lifting mechanism enable fast and efficient loading and unloading of soil, rock, and debris.
Specialized in transporting heavy minerals, the large-capacity mining tipper is widely used in the energy and construction industries. It provides a reliable and efficient solution for long-distance transport of coal to power plants, iron ore to steel mills, and limestone to cement factories.
The gross weight is 92 tons, with a load capacity of 60 tons, making it suitable for heavy mineral and material transport.
Yes, the dump body is made of high-enforced steel or manganese material, which is wear-resistant and can withstand the abrasion of sharp minerals, ores, and aggregates.
The truck comes with left-hand driving (LHD) as standard, with customizable options available upon request to meet regional requirements.
The tires hold ECE, GCC, ISO, and DOT certifications, ensuring high quality, durability, and compliance with international safety standards.
We ship from Qingdao and Shanghai ports, with flexible arrangements possible based on your location and logistics needs. Payment terms include T/T and L/C.
The 90 Tons Heavy Duty Mineral Dump Truck is a rugged, high-capacity vehicle designed exclusively for large-scale mining, quarrying, and heavy material transport. Manufactured by Sinotruk (JSIE), this industrial-grade mining dump truck combines a 90-ton payload capacity, powerful Weichai engine, and reinforced mining-grade construction to excel in harsh environments such as open-pit mines, quarries, and large construction sites. Whether hauling coal, iron ore, limestone, or overburden, the large-capacity mining tipper delivers exceptional productivity, low operating costs, and long service life. With its robust hydraulic lifting system, ergonomic cabin, and advanced safety features, it is the ultimate solution for high-intensity mineral transportation and earthmoving tasks.
The 90 Tons Heavy Duty Mineral Dump Truck is a rugged, high-capacity vehicle designed exclusively for large-scale mining, quarrying, and heavy material transport. Manufactured by Sinotruk (JSIE), this industrial-grade mining dump truck combines a 90-ton payload capacity, powerful Weichai engine, and reinforced mining-grade construction to excel in harsh environments such as open-pit mines, quarries, and large construction sites. Whether hauling coal, iron ore, limestone, or overburden, the large-capacity mining tipper delivers exceptional productivity, low operating costs, and long service life. With its robust hydraulic lifting system, ergonomic cabin, and advanced safety features, it is the ultimate solution for high-intensity mineral transportation and earthmoving tasks.
