Sinotruk HOWO 4X2 Foam Fire Truck

Max Speed(km/h)

100

GVW(kg)

10200

Rated Load   Capacity(kg)

3750

Curb Weight(kg)

6000

Cab

3+3

Approach/Departure   Angel(°)

17/12

ABS System

with

F/R Overhang(mm)

1110/2100

Chassis   Parameters

Model

QL1110ANKAY

Manufacture

Qingling Motors   Co., Ltd.

Others

Tank Capacity:

3.750 cubic   meters;

Water Tank   Capacity:

2.950 cubic   meters;

Water Tank   Dimensions:

1880 × 1310 ×   1250 mm;

Type B Foam   Solution Tank Capacity:

0.8 cubic meters;

Foam Solution   Tank Dimensions:

510 × 1310 × 1250   m

Integrated side   protection structure. The rear protection device is made of Q235A steel with   a cross-sectional dimension of 100×100mm, connected to the vehicle via bolted   joints. The rear protection ground clearance is 435mm. The ABS system is   manufactured by Zhejiang Asia-Pacific Mechanical  Electronic Co., Ltd., model APG3550500H1.   The main specialized equipment includes a fire pump and fire monitor.
